PV&T class M #851 in blue & white

The class M steeplecabs are another design for the D&H South electrification; B+B+B like 719, but with modern internals (& a slightly lower profile so it can fit through the ancient tunnels under Baltimore) so they can run under both the PV&T’s 3kvdc & the C&PD/NE Corridor’s 12.5vac.

These locomotives were actually designed before the class L, but weren’t ordered until the D&H got permission to string wire over Norfolk Southern’s just-acquired line from Sunbury to Harrisburg, so the first one came out of the Portland Shops in fall of 1999, after 799 was already running on D&H’s route from Harrisburg to Washington, DC.

LT&L class M2 #1151 in blue & white

In 2002, another 16 motors were ordered, but were built with upgraded electronics and were placed into class M2.

TdM M3 #1410 in orange & green

In 2023, the Portland Shops started producing a third version of the class; class M3, like the streamlined class K7, uses an updated version of the drivetrain that the class L motor has. 38 have been built for the Providence & Worcester, the Old Colony, and the Ontario Southwestern’s China Tunnel Railway project.
